3KW 4KW 5KW 6KW Hybrid Solar Inverter Single Phase For Energy Storage System

Product Categories
Shenzhen Zhongguanda Technology Co., Ltd.
Contact Now

3KW 4KW 5KW 6KW Hybrid Solar Inverter Single Phase For Energy Storage System

  • 1
  • 2
  • 3

Brand Name : ZGD

Certification : CE

Place of Origin : SHENZHEN

MOQ : 1 sets

Price : $230.00/Sets 1-19 Sets

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000 sets per month

Delivery Time : 7~15 working days

Packaging Details : Wood plywood packing

Rated power : 5500W

Waveform : Purer Sine Wave

Protection : Short Circuit Overload Overvolt Overtemp

Transfer Time : 10 Ms (For Personal Computers)

Application : Home Solar Power System

Output Frequency : 50/60HZ

Contact Now

Product Paramenters
MODEL NAME
HMK PLUS (WITHOU BATTERY) CHEAPER
RATED POWER
5500W
INPUT
Voltage
230 VAC
Selectable Voltage Range
170-280 VAC (For Personal Computers)
90-280 VAC (For Home Appliances)
Frequency Range
50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)
230VAC ± 5%
Surge Power
11000VA
Efficiency (Peak) PV to INV.
97%
Efficiency (Peak) Battery to INV.
94%
Transfer Time
10 ms (For Personal Computers) ; 20 ms (For Home Appliances)
Output Port
Dual output
Waveform
Pure sine wave
BATTERY & AC CHARGER
Battery Voltage
48 VDC
Floating Charge Voltage
54 VDC
Overcharge Protection
61 VDC
Maximum Charge Current
80 A(From grid)
SOC display
Shows battery State of charge in percentage and in voltage as well
Sleeping Mode
YES
Battery voltage low cut off selectable
42V-49V
Battery High voltage range selectable
50-60V
Works without Battery
YES
SOLAR CHARGER
Maximum PV Array Power
6000W
MPPT Range @ Operating Voltage
100 ~ 430 VDC
Maximum PV Array Open Circuit Voltage
450 VDC
Maximum Charging Current
100A
Maximum Efficiency
98%
PHYSICAL
Dimension, D x W x H (mm)
100 x 310 x 380
Net Weight (kgs)
10.6
Communication interface
RS485/ Wifi option(BMS Compatible with lithium battery using RS-485)
LCD display
General small LCD
OPERATING ENVIRONMENT
Humidity
5% to 95% Relative Humidity(Non-condensing)
Operating Temperature
0°C - 55°C
Storage Temperature
–15°C - 60°C
Features
3KW 4KW 5KW 6KW Hybrid Solar Inverter Single Phase For Energy Storage System
* Pure Sine wave inverter

* Configurable input voltage range for home appliances and personal computer via LCD setting

* Configurable battery charging current based on applications via LCD setting

* Configurable AC/Solar Charger/Controller priority via LCD setting

* Compatible to mains voltage or generator power

* Auto restart while AC is recovering

* Overload/Over temperature/ Short circuit protection

* MPPT Smart battery charger controller design for optimized battery performance

* Cold start function
3KW 4KW 5KW 6KW Hybrid Solar Inverter Single Phase For Energy Storage System
